Sleeve Anchor with Flange Nut

Sleeve Anchors with Hex Flange Nuts, a versatile and reliable mechanical fastener designed for securing objects to solid base materials like concrete, brick, or stone.
This anchor system consists of a threaded stud, a slotted expansion sleeve, and a hexagonal flange nut. The sleeve features a color-passivated zinc plating (gold finish), which offers excellent corrosion resistance for indoor and sheltered outdoor applications. When the nut is tightened, the stud is drawn upward, forcing the cone

Sales Count Click

Sales Count

Click

Select the number of specifications

Please check the product information you want!

Product Detail

Size (Diameter x Length)	Drill Bit Size	Thread Length	Sleeve Diameter	Min. Fixing Thickness
M6 x 60mm	10mm	25mm	10mm	5mm
M8 x 80mm	12mm	32mm	12mm	10mm
M10 x 100mm	14mm	40mm	14mm	15mm
M12 x 120mm	16mm	50mm	16mm	20mm
M16 x 150mm	20mm	60mm	20mm	25mm
